Cov khoom muag
Peb 3D Optical Profiler ua ke nrog siab -precision scanning thiab siab -precision algorithms tuaj yeem ua tiav qhov kev ntsuam xyuas saum toj kawg nkaus ntawm nanometer mus rau millimeter nplai, suav nrog roughness, cov kauj ruam, nto profile, curvature thiab lwm yam tsis. Nws tau siv dav hauv cov khoom siv hluav taws xob, cov khoom siv kho qhov muag, biochips, hlau qhov chaw, precision machining thiab lwm yam lag luam vim nws tsis yog -kev sib cuag (tsis yog- kev kuaj kev puas tsuaj), tsis tas yuav tsum muaj cov qauv saum npoo rigidity, siab precision thiab ceev scanning.
Qhov zoo
Plaub hom kev ntsuas sib txawv-brightfield kev soj ntsuam, lub teeb dawb interferometry, confocal microscopy, thiab qhov tob ntawm qhov chaw fusion- tau muab tso rau hauv ib lub tshuab tsom iav kom tau raws li qhov xav tau ntawm kev ntsuas hauv ntau yam xwm txheej.
01
Kev soj ntsuam cov txiaj ntsig tuaj yeem ua tiav nrog sub-nanometer rau nanometer precision hauv ntau hom kev ntsuas.
02
Qhov tshwj xeeb AI algorithm tsom xam tus qauv kom ua tiav 'tsis muaj ncua' cov txiaj ntsig cov txiaj ntsig thiab kev paub 'Ib qho-Nyem ' qhov ntsuas ntsuas.
03
Peb muab "modular" customized haumxeeb khoom kom tau raws li lub workflow cov hauj lwm ntawm ntau yam scenarios seb nws yog tshwj xeeb cov qauv yuav tsum tau los yog haumxeeb xav tau kev pab.
04
Features ib tug revolutionary integrated tsim uas combines lub optical system thiab sensors rau hauv ib lub tsev. Qhov kev tsim qauv compact no tsis tsuas yog txhim kho cov neeg siv- kev phooj ywg tab sis kuj tseem ua rau muaj kev ruaj ntseg zoo heev, ua kom muaj kev vam meej nyob rau hauv txhua qhov kev ua haujlwm.
05
Daim ntawv thov
Qhov no 3D Optical Profiler, nrog nws cov cuab yeej kho qhov muag pom tau zoo, ua tau raws li cov kev xav tau nruj ntawm kev lag luam sib txawv thiab cov xwm txheej thov. Txawm hais tias nws yog biochip, semiconductor, kho qhov muag pom cov khoom, peb muab cov kev soj ntsuam thiab ntsuas kev daws teeb meem kom haum rau koj cov kev xav tau tshwj xeeb.Cov koob no tsis tsuas yog nta 3D duab thev naus laus zis tab sis kuj suav nrog ntau yam tshiab, muab cov neeg siv kev soj ntsuam zoo.
Tsis muaj
|
Kev ntsuas hom |
Dawb lub teeb cuam tshuam / Qhov tob ntawm thaj chaw fusion / Confocal |
|
Hom kev soj ntsuam |
Cov duab (2D / 3D), Morphology, Dimensions, Roughness, Thickness, thiab lwm yam. |
|
Lub teeb Source |
Lub teeb dawb LED, Spectral Range: 420-700 nm |
|
Nosepiece |
6-Txoj haujlwm @ tag nrho lub cev muaj zog; Repeat Positioning Accuracy: 0.001 degree |
|
Lub koob yees duab |
1936 × 1464 (132.2 fps) |
|
Z Theem Taug Kev / Scanning ntau yam |
Kev ncua deb: 100 mm; Scanning ntau: 10 mm |
|
Roughness RMS Repeatability |
0, 008nm |
|
Kauj Ruam Repeatability |
0.1 % (10 μm) |
|
XY Theem Range |
100 hli × 100 hli @ tag nrho motorized |
|
Tswv yim - qaij theem |
± 3℃suab hloov @ tag nrho lub cev muaj zog |
|
Qhov hnyav |
7 5kg |
|
Qhov ntev |
516 hli × 430 hli × 550 hli |
|
Environmental Requirements |
Pom zoo ambient kub 23 degree, humidity20% - 50% |
Daim ntawv pov thawjion
Peb lub tuam txhab cov khoom siv kho qhov muag (nrog rau cov khoom siv kho qhov muag thiab cov khoom siv kho qhov muag) tau ua tiav tau txais ntawv pov thawj ISO.
